Imperial G7088 Lockcase 76mm
  • Imperial G7088 Lockcase 76mm
  • Imperial Locks G7088 sizes

Imperial G7088 Dual Profile Nightlatch, 76mm

$53.83
Tax excluded

Imperial/Guardian/Enfield G7088 dual profile mortice nightlatch lockcase with anti-thrust bolt.

Finish: Stainless Steel forend and striker plate

Case Depth: 76mm

Quantity
Out-of-Stock

  Privacy/Security policy: We only use your information to process your orders and enquiries.

We do not sell or pass on your data to third parties. We do not use cookies.

  Delivery policy: We post/deliver orders every day except weekends and bank/public holidays.

Invoices enclosed with order (also availiable on-line).

  Return policy: Most goods may be returned within 7 days, call for authorised return number.

Exceptions include: cut keys, special orders and worshop serviced items.

Operation

Latchbolt operated by key from outside and lever handle or turn knob inside using a single cylinder or by key from either side using a double cylinder. When the door is shut the bolt is locked against end pressure. The bolt may be held in the withdrawn position by means of a reverse turn of the key. Use with turn operated cylinders is not recommended

Case

Pierced to accept 38mm centre horizontally opposed bolt through fixing furniture Pierced to accept 20mm centre bolt through fixing escutcheons

Striker Plate

Type W

Latchbolt

Brass, reversible. Projection 12mm

Anti Thrust Slide

SCP, effective at door gaps up to 6mm

Follower

Brass, to suit 8mm square spindle. One-way action. Sprung to suit sprung lever handle furniture only

Cylinder

Not supplied. May be used with the following cylinders: a) Key outside such as Guardian G9000 or G9010 b) Key either side such as Guardian G9001 or G9011

Rebate Units
To Suit

G3073-13mm G3074-19mm G3075-25mm (Handed)

A Lock Case

63mm, 76mm, 101mm

B Backset

45mm, 57mm, 82mm

C Centres

EURO 49.5mm OVAL 50mm

IMP-G7088-76SS
